〓 WA TYPE
|
| ● EXTERNAL DIMENSIONS UNIT：mm(外形尺寸) |
|
|
|
|
T-2 TYPE
|
| ●SPECIFICATION TABLE |
PART
NUMBER
品名
|
INDUCTANCE
(uH)
1KHz/OA
电感值 |
INDUCTANCE
(uH)
1KHz/maxIDC
电感值 |
IDC(max)
(A)
定格电流
|
DC
RESISTANCE
(Ω)max
直流电阻 |
DIMENSION(mm)
（尺寸）
|
WEIGHT
(g/pcs) 重量
|
A
|
D
|
| T-2-5ROM-2026 |
5.00 |
4.90 |
0.50 |
0.007 |
7.50 |
4.50 |
0.40 |
| T-2-9ROM-2026 |
9.00 |
8.80 |
0.30 |
0.011 |
8.00 |
4.50 |
0.20 |
| T-2-150M-2026 |
15.00 |
13.50 |
0.50 |
0.070 |
7.50 |
4.50 |
0.40 |
| T-2-200M-2026 |
20.00 |
19.80 |
0.20 |
0.198 |
7.50 |
4.00 |
0.20 |
| T-2-270M-2026 |
27.00 |
27.00 |
0.10 |
0.033 |
7.50 |
4.00 |
0.20 |
| T-2-270M-2026 |
27.00 |
25.50 |
0.30 |
0.031 |
8.00 |
4.50 |
0.20 |
| T-2-100M-3026 |
10.00 |
7.70 |
2.00 |
0.017 |
12.00 |
7.00 |
1.60 |
| T-2-120M-3026 |
12.00 |
10.70 |
1.00 |
0.040 |
10.50 |
6.00 |
1.20 |
| T-2-320M-3026 |
32.00 |
25.00 |
1.00 |
0.065 |
12.00 |
7.00 |
1.40 |
| T-2-370M-3026 |
37.00 |
33.70 |
0.50 |
0.134 |
10.00 |
5.50 |
1.00 |
| T-2-141M-3026 |
140.00 |
107.00 |
0.50 |
0.265 |
10.00 |
6.00 |
1.20 |
| T-2-8R2M-3726 |
8.20 |
7.20 |
2.00 |
0.017 |
14.50 |
7.00 |
2.00 |
| T-2-220M-3726 |
22.00 |
17.00 |
2.00 |
0.030 |
14.50 |
7.50 |
2.40 |
| T-2-240M-3726 |
24.00 |
22.00 |
1.00 |
0.055 |
13.50 |
6.00 |
1.60 |
| T-2-560M-3726 |
56.00 |
53.00 |
0.50 |
0.181 |
12.50 |
5.50 |
1.40 |
| T-2-680M-3726 |
68.00 |
53.00 |
1.00 |
0.095 |
13.50 |
6.50 |
2.00 |
| T-2-241M-3726 |
240.00 |
190.00 |
0.50 |
0.360 |
13.00 |
6.50 |
1.60 |
| T-2-150M-4426 |
15.00 |
12.60 |
2.00 |
0.023 |
15.50 |
7.50 |
2.80 |
| T-2-430M-4426 |
43.00 |
37.00 |
1.00 |
0.074 |
14.50 |
7.00 |
2.60 |
| T-2-680M-4426 |
68.00 |
42.00 |
2.00 |
0.056 |
15.50 |
9.00 |
3.80 |
| T-2-111M-4426 |
110.00 |
100.00 |
0.50 |
0.250 |
14.00 |
6.50 |
2.40 |
| T-2-141M-4426 |
140.00 |
104.00 |
1.00 |
0.140 |
15.00 |
7.50 |
3.20 |
| T-2-361M-4426 |
360.00 |
285.00 |
0.50 |
0.460 |
14.50 |
7.50 |
2.80 |
| T-2-200M-5026 |
20.00 |
15.00 |
3.00 |
0.021 |
17.50 |
9.00 |
4.40 |
| T-2-300M-5026 |
30.00 |
25.00 |
2.00 |
0.035 |
17.00 |
8.50 |
4.00 |
| T-2-600M-5026 |
60.00 |
35.00 |
3.00 |
0.038 |
18.00 |
10.0 |
5.80 |
| T-2-680M-5026 |
68.00 |
60.00 |
1.00 |
0.101 |
16.00 |
7.50 |
3.60 |
| T-2-10IM-5026 |
100.00 |
63.00 |
2.00 |
0.081 |
17.00 |
9.00 |
5.20 |
| T-2-221M-5026 |
220.00 |
162.00 |
1.00 |
0.190 |
16.50 |
8.00 |
4.40 |
| T-2-220M-6026 |
22.00 |
15.00 |
5.00 |
0.014 |
21.50 |
11.50 |
8.00 |
| T-2-290M-6026 |
29.00 |
20.00 |
4.00 |
0.020 |
21.00 |
11.00 |
7.80 |
| T-2-350M-6026 |
35.00 |
28。oo |
3.00 |
0.026 |
20.50 |
10.50 |
7.60 |
| T-2-580M-6026 |
58.00 |
45.00 |
2.00 |
0.061 |
20.00 |
10.00 |
7.20 |
| T-2-900M-6026 |
90.00 |
52.00 |
3.00 |
0.044 |
20.50 |
12.50 |
9.20 |
| T-2-111M-6026 |
110.00 |
79.00 |
2.00 |
O．069 |
19.50 |
10.00 |
8.00 |
| T-2-131M-6026 |
130.00 |
116.00 |
1.00 |
0.146 |
19.00 |
9.00 |
6.40 |
| T-2471M-6026 |
470.00 |
310.00 |
1.00 |
0.286 |
21.00 |
11.00 |
7.60 |
| T-2-250M-6026 |
25.00 |
18.00 |
5.00 |
0.016 |
24.00 |
10.50 |
9.20 |
| T-2-320M-6826 |
32.00 |
24.00 |
4.00 |
0.021 |
23.50 |
10.00 |
9.00 |
| T-2-430M-6826 |
43.00 |
30.00 |
3.00 |
0.030 |
23.00 |
9.50 |
8.80 |
| T-2-650M-6826 |
65.00 |
55.00 |
2.00 |
0.055 |
22.00 |
9.00 |
8.20 |
| T-2-111M-6826 |
110.00 |
56.00 |
4.00 |
0.042 |
23.50 |
11.00 |
11.40 |
| T-2-131M-6826 |
130.00 |
77.00 |
3.00 |
0.055 |
23.00 |
10.50 |
10.40 |
| T-2-151M-6826 |
150.00 |
137.00 |
1.00 |
0.159 |
21.50 |
7.50 |
7.60 |
|
|
| ● PART NUMBERING SYSTEM(品名系统) |
|
|
1 SERIES NAME 品名 指磁环线圈
3 INDUCTANCE 电感值 前两位为有效数字，第三位表零的个数
4 TOLERANCE CODE 公差 J:±5%,K:±10%,L:±15% M:±20%,P:±25% ,N:±30%s
5 DIMENSIONS 尺寸 外径（英寸）
5 CORE MAKING 指磁环材质 |
| ● FEATURES（特性） |
High Saturation Materal. Wide Inductance Range. High Current Capability .
Low DC resistance. |
| ● APPLICATIONS (用途) |
SwiT-2hing Regulators . Automotive Systems. PowerAmplifiers. Power Supplies.
SCR and Triac Controls. Speaker Crossover Networks. EM/RFI Suppression. |
| ● GENERAL ConDITIONS (一般条件) |
Operating temperature:-55℃ ～+55℃ . Storage temperature:-40 ℃～+40℃
Inductance range:l u H～0000 u H. Current rating based on current density
about 8A/mm2 I ron Power Core Material 26:50Hz～100KHz . Iron Power Core
Material 52:10KHz～500KHz |
| ★ Design As Gustomer's Requested Specifications. ( 根据客户要求参数来设计！) |
