〓 WA TYPE
|
| ● EXTERNAL DIMENSIONS UNIT：mm(外形尺寸) |
|
|
|
|
T-2 TYPE
|
| ●SPECIFICATION TABLE |
PART
NUMBER
品名
|
INDUCTANCE
(uH)
1KHz/OA
电感值 |
INDUCTANCE
(uH)
1KHz/maxIDC
电感值 |
IDC(max)
(A)
定格电流
|
DC
RESISTANCE
(Ω)max
直流电阻 |
DIMENSION(mm)
（尺寸）
|
WEIGHT
(g/pcs) 重量
|
A
|
D
|
| T-2-231M-6826 |
230.00 |
148.00 |
2.00 |
0.108 |
22.50 |
9.500 |
9.800 |
| T-2-500M-8026 |
50.00 |
33.00 |
5.00 |
0.022 |
26.50 |
12.00 |
14.20 |
| T-2-600M-8026 |
60.00 |
42.00 |
4.00 |
0.030 |
26.50 |
11.50 |
13.70 |
| T-2-750M-8026 |
75.00 |
54.00 |
3.00 |
0.039 |
25.50 |
11.00 |
13.00 |
| T-2-820M-8026 |
82.00 |
60.00 |
3.00 |
0.042 |
24.50 |
10.50 |
13.00 |
| T-2-10IM-8026 |
100.00 |
53.00 |
5.00 |
0.033 |
26.50 |
12.50 |
16.80 |
| T-2-151M-8026 |
150.00 |
68.00 |
5.00 |
0.042 |
27.00 |
13.50 |
18.00 |
| T-2-221M-8026 |
220.00 |
105.00 |
4.00 |
0.059 |
26.50 |
13.00 |
17.90 |
| T-2-271M-8026 |
270.00 |
140.00 |
3.00 |
0.081 |
26.00 |
12.00 |
16.60 |
| T-2-321M-8026 |
320.00 |
193.00 |
2.00 |
0.131 |
25.00 |
10.50 |
14.00 |
| T-2-431M-8026 |
430.00 |
246.00 |
2.00 |
0.150 |
25.00 |
11.00 |
15.00 |
| T-2-961M-8026 |
960.00 |
625.00 |
1.00 |
0.438 |
25.00 |
11.00 |
13.00 |
| T-2-900M-9026 |
90.00 |
54.00 |
5.00 |
0.034 |
29.50 |
15.50 |
23.60 |
| T-2-141M-9026 |
140.00 |
98.00 |
3.00 |
0.064 |
28.00 |
14.50 |
22.00 |
| T-2-20IM-9026 |
200.00 |
154.00 |
2.00 |
0.114 |
28.00 |
14.00 |
20.80 |
| T-2-321M-9026 |
320.00 |
120.00 |
5.00 |
0.068 |
29.50 |
17.00 |
29.60 |
| T-2-451M-9026 |
450.00 |
280.00 |
2.00 |
0.174 |
28.00 |
14.00 |
23.00 |
| T-2-471M-9026 |
470.00 |
398.00 |
1.00 |
0.354 |
26.50 |
13.00 |
19.50 |
| T-2-471M-9026 |
470.00 |
225.00 |
3.00 |
0.188 |
28.50 |
15.50 |
27.00 |
| T-2-182M-9026 |
1800.00 |
1130.00 |
1.00 |
0.680 |
27.50 |
14.00 |
22.40 |
| T-2-820M-9426 |
82.00 |
52.00 |
5.00 |
0.033 |
31.00 |
15.50 |
22.40 |
| T-2-10IM-9426 |
100.00 |
69.00 |
4.00 |
0.042 |
29.50 |
13.50 |
21.90 |
| T-2-131M-9426 |
130.00 |
96.00 |
3.00 |
0.061 |
29.00 |
13.00 |
21.60 |
| T-2-221M-9426 |
220.00 |
170.00 |
2.00 |
0.121 |
28.50 |
12.00 |
20.60 |
| T-2-30IM-9426 |
300.00 |
120.00 |
5.00 |
0.064 |
30.00 |
15.50 |
28.80 |
| T-2-391M-9426 |
390.00 |
165.00 |
4.00 |
0.088 |
29.50 |
15.00 |
27.20 |
| T-2-471M-9426 |
470.00 |
400.00 |
1.00 |
0.342 |
27.50 |
11.50 |
19.00 |
| T-2-50IM-9426 |
500.00 |
242.00 |
3.00 |
0.124 |
29.00 |
14.00 |
26.00 |
| T-2-781M-9426 |
780.00 |
428.00 |
2.00 |
0.225 |
28.50 |
13.50 |
24.10 |
| T-2-132M-9426 |
1300.00 |
933.00 |
1.00 |
0.585 |
28.50 |
12.50 |
21.20 |
| T-2-300M-10626 |
30.00 |
21.00 |
10.0 |
0.009 |
36.00 |
19.50 |
42.00 |
| T-2-350M-10626 |
35.00 |
25.00 |
10.0 |
0.010 |
36.00 |
19.50 |
43.00 |
| T-2-560M-10626 |
56.00 |
41.50 |
7.00 |
0.020 |
34.00 |
18.00 |
40.00 |
| T-2-680M-10626 |
68.00 |
46.00 |
7.00 |
0.021 |
34.00 |
18.00 |
40.00 |
| T-2-820M-10626 |
82.00 |
53.00 |
7.00 |
0.023 |
34.00 |
18.00 |
41.00 |
| T-2-10IM-10626 |
100.00 |
75.00 |
5.00 |
0.036 |
33.50 |
17.00 |
39.00 |
| T-2-151M-10626 |
150.00 |
110.00 |
4.00 |
0.053 |
32.50 |
16.50 |
38.40 |
| T-2-20IM-10626 |
200.00 |
157.00 |
3.00 |
0.078 |
32.00 |
16.00 |
37.80 |
| T-2-30IM-10626 |
300.00 |
250.00 |
2.00 |
0.142 |
31.50 |
15.50 |
37.80 |
| T-2-851M-10626 |
850.00 |
567.00 |
2.00 |
0.211 |
32.50 |
16.50 |
41.80 |
| T-2-750M-13026 |
75.00 |
43.00 |
10.0 |
0.014 |
42.00 |
19.50 |
64.00 |
| T-2-131M-13026 |
130.00 |
79.00 |
7.00 |
0.031 |
41.00 |
18.00 |
58.00 |
| T-2-20IM-13026 |
200.00 |
134.00 |
5.00 |
0.056 |
39.00 |
17.00 |
55.60 |
| T-2-251M-13026 |
250.00 |
105.00 |
10.0 |
0.027 |
42.50 |
21.50 |
82.00 |
| T-2-471M-13026 |
470.00 |
190.00 |
7.00 |
0.064 |
40.50 |
19.50 |
72.00 |
| T-2-681M-13026 |
680.00 |
295.00 |
5.00 |
0.105 |
39.00 |
18.50 |
65.20 |
|
|
| ● PART NUMBERING SYSTEM(品名系统) |
|
|
1 SERIES NAME 品名 指磁环线圈
3 INDUCTANCE 电感值 前两位为有效数字，第三位表零的个数
4 TOLERANCE CODE 公差 J:±5%,K:±10%,L:±15% M:±20%,P:±25% ,N:±30%s
5 DIMENSIONS 尺寸 外径（英寸）
5 CORE MAKING 指磁环材质 |
| ● FEATURES（特性） |
High Saturation Materal. Wide Inductance Range. High Current Capability .
Low DC resistance. |
| ● APPLICATIONS (用途) |
SwiT-2hing Regulators . Automotive Systems. PowerAmplifiers. Power Supplies.
SCR and Triac Controls. Speaker Crossover Networks. EM/RFI Suppression. |
| ● GENERAL ConDITIONS (一般条件) |
Operating temperature:-55℃ ～+55℃ . Storage temperature:-40 ℃～+40℃
Inductance range:l u H～0000 u H. Current rating based on current density
about 8A/mm2 I ron Power Core Material 26:50Hz～100KHz . Iron Power Core
Material 52:10KHz～500KHz |
| ★ Design As Gustomer's Requested Specifications. ( 根据客户要求参数来设计！) |
